Bernardo Metal Lathe Spare Parts – Maintain and Repair Your Machine

Are you looking for Bernardo metal lathe spare parts to replace a worn drive belt, repair a transmission problem or restore your machine to proper working condition?

At Probois Machinoutils, we offer a selection of replacement parts for Bernardo metalworking lathes, designed to make maintenance, repairs and the replacement of mechanical and electrical components easier.

Bernardo metal lathes are used in mechanical workshops, industrial maintenance, model engineering and precision machining.

They can perform a wide range of operations, including cylindrical turning, facing, drilling, boring, thread cutting and longitudinal turning of metal workpieces.

Their proper operation depends on several essential components, including the motor, transmission system, spindle, feed gearbox, leadscrew, slides, tailstock and electrical components.

Over time and with regular use, certain parts may wear out or require replacement.

Our category includes drive belts for Bernardo Profi 400V, Profi 550 and Profi 750 metal lathes, as well as motor carbon brushes, brush holders and electrical components compatible with certain Bernardo machines.

Spare Parts for Bernardo Profi 400V, Profi 550 and Profi 750 Metal Lathes

Bernardo Profi metal lathes are designed for various metal machining operations.

Depending on the model, these machines feature transmission systems, speed adjustment mechanisms and feed controls suited to different turning applications.

Our catalogue includes spare parts for several models:

  • Bernardo Profi 400V: 5M375 and 5M387 timing belts, depending on the machine version and transmission arrangement.

  • Bernardo Profi 550WQV: 750 mm V-belt.

  • Bernardo Profi 550 and Profi 750: 730 mm timing belt for compatible versions.

  • Bernardo Profi 550WQV, 550WQ, 550LZ and 750LZ: certain motor carbon brushes, depending on the part reference.

  • Bernardo Profi 700BWV, 700BQV and 700TOP: certain motor carbon brushes, depending on the part reference.

Other components may also be compatible with several Bernardo metal lathes and milling machines.

A part suitable for one Bernardo Profi model is not necessarily compatible with every machine in the same range.

Always check the exact machine reference, production version and specifications of the original component.

Drive Belts for Bernardo Metal Lathes

The drive belt of a Bernardo metal lathe transfers power from the motor to the machine's mechanical drive system.

Depending on the lathe design, it may drive the spindle directly or transmit movement through a pulley arrangement.

A drive belt in good condition helps ensure:

  • Smooth and consistent power transmission.

  • Stable spindle rotation.

  • Quieter mechanical operation.

  • Reduced belt slipping.

  • More consistent machining performance.

  • Fewer transmission-related vibrations.

Over time, a belt may stretch, crack, lose teeth or show other signs of wear.

A damaged belt can cause power loss, unusual noises or irregular rotation.

When replacing a Bernardo lathe drive belt, it is essential to match the original belt profile, dimensions and part reference.

5M375 and 5M387 Timing Belts for Bernardo Profi 400V

We offer 5M375 and 5M387 timing belts for the Bernardo Profi 400V metal lathe, also listed for certain Holzmann machines.

These two belts have different specifications:

  • 5M375: timing belt with a 5 mm tooth pitch and a nominal length of 375 mm.

  • 5M387: timing belt with a 5 mm tooth pitch and a nominal length of 387 mm.

Although both belong to the same family of synchronous belts, their lengths are different.

The 5M375 and 5M387 timing belts must not be considered automatically interchangeable.

The correct choice depends on the machine's transmission arrangement and the belt originally fitted.

Before ordering, check the markings on the old belt and the information provided in the machine manual or exploded parts diagram.

It is also advisable to inspect the pulleys and their alignment to prevent premature wear of the replacement belt.

V-Belt for Bernardo Profi 550WQV Metal Lathe

The V-belt for the Bernardo Profi 550WQV metal lathe is part of the machine's mechanical power transmission system.

Our catalogue includes a 750 mm V-belt listed for this model.

A V-belt transmits power through friction between its sides and the corresponding pulley grooves.

When correctly sized and tensioned, it provides smooth and reliable power transmission.

A worn V-belt may cause:

  • Slipping during machining.

  • Loss of spindle power.

  • Vibrations.

  • Transmission noises.

  • Abnormal heat build-up.

  • Difficulty maintaining consistent rotation.

Before replacing the belt, it is important to check the exact dimensions and profile of the original component.

Belt length alone is not sufficient to guarantee V-belt compatibility.

730 mm Timing Belt for Bernardo Profi 550 and Profi 750

We also offer a 730 mm timing belt for certain Bernardo Profi 550 and Profi 750 metal lathes.

This type of belt provides synchronised power transmission between matching toothed pulleys.

Unlike a conventional V-belt, a timing belt engages with the teeth of the pulleys.

Its tooth profile and pitch must therefore match the transmission system precisely.

A damaged timing belt may show:

  • Worn or missing teeth.

  • Cracks on its surface.

  • Deformation.

  • Uneven wear.

  • Abnormal rubbing marks.

When replacing the belt, the pulleys should also be inspected for damage and foreign objects.

Compatibility must be confirmed according to the exact Bernardo Profi 550 or Profi 750 version.

Motor Carbon Brushes for Bernardo Metal Lathes

Motor carbon brushes for Bernardo metal lathes supply electrical current to the rotating part of commutator-type motors.

They maintain electrical contact with the commutator through the pressure applied by their springs.

As the machine operates, the carbon brushes gradually wear down.

Brushes that are excessively worn or damaged may cause:

  • Difficulty starting the motor.

  • Intermittent electrical interruptions.

  • Loss of power.

  • Irregular motor operation.

  • Abnormal sparking at the commutator.

  • Complete motor failure.

Our catalogue includes pairs of carbon brushes for certain Bernardo Profi 550, Profi 700 and Profi 750 machines, as well as compatible metal milling machines.

The exact references depend on the model and the motor fitted.

Motor carbon brushes should be replaced in pairs when their condition requires replacement.

Their dimensions, shape, electrical connections and technical characteristics must match the original components.

Carbon Brush Holders for Bernardo and Holzmann Metal Lathes

Carbon brush holders for Bernardo metal lathes keep the motor brushes correctly positioned and guide them against the commutator.

They allow the brushes to move as they gradually wear down.

A damaged brush holder may prevent the carbon brush from sliding freely or maintaining consistent electrical contact.

Possible problems include:

  • A carbon brush becoming stuck in its holder.

  • A damaged spring.

  • Poor electrical contact.

  • Abnormal heat build-up.

  • Intermittent motor operation.

  • Damage to the brush housing.

We offer carbon brush holders for certain Bernardo and Holzmann metal lathes and milling machines, depending on model compatibility.

Before ordering, check the holder's shape, dimensions and part reference.

A brush holder that looks similar to the original component is not necessarily compatible.

Potentiometers and Variable Speed Control Components

Some Bernardo metal lathes are equipped with an electronic spindle speed control system.

On these models, a speed control potentiometer sends a control signal to the electronic motor controller.

A faulty potentiometer may cause:

  • Inability to adjust the spindle speed.

  • Irregular speed changes.

  • No response when turning the control knob.

  • Intermittent speed control operation.

Our catalogue includes a WX14-12 potentiometer, listed for certain Holzmann and Bernardo machines.

Compatibility must be checked against the specifications of the original potentiometer and the machine concerned.

Irregular speed control does not necessarily mean that the potentiometer is faulty.

The problem may also originate from the electronic control board, electrical connections, motor or power supply.

A proper diagnosis is therefore necessary before carrying out repairs.

Gears, Change Wheels and Feed Mechanisms for Metal Lathes

Metal lathe gears and change wheels transmit mechanical movement, particularly for certain feed and thread-cutting functions.

Depending on the lathe design, these components may drive the leadscrew or allow different transmission ratios to be selected.

A worn or damaged gear may cause:

  • Unusual mechanical noises.

  • Difficulty engaging the drive.

  • Irregular feed movement.

  • Thread-cutting problems.

  • Transmission jamming.

  • Accelerated wear of other gears.

When replacing a gear, several characteristics must be checked:

  • Number of teeth.

  • Gear module.

  • Outside diameter.

  • Bore diameter.

  • Gear width.

  • Mounting arrangement.

These components are not universal.

The gear reference and its position number on the exploded parts diagram are essential when searching for a suitable replacement.

Availability depends on the machine model and sourcing possibilities.

Spindle, Bearings and Chuck for Bernardo Metal Lathes

The spindle of a Bernardo metal lathe rotates the workpiece during machining.

It is generally supported by bearings whose condition contributes to the machine's accuracy.

The chuck holds the workpiece securely during turning operations.

Problems affecting these components may cause:

  • Excessive spindle play.

  • Vibrations during machining.

  • Bearing noises.

  • Excessive heat build-up.

  • Runout or concentricity problems.

  • Poor surface finish on machined parts.

Before replacing a component, it is important to check the chuck mounting, spindle adjustments and bearing condition.

On certain lathes, incorrect bearing preload adjustment can also cause overheating or difficult spindle rotation.

Any work on spindle bearings must follow the adjustment procedures specified by the manufacturer.

Replacement components must be identified according to the exact machine model.

Slides, Handwheels and Adjustment Mechanisms

The slides of a metal lathe allow the cutting tool to be positioned and moved accurately.

They include various mechanisms such as feed screws, nuts, slideways, adjustable gibs and handwheels.

Over time, some components may develop wear or mechanical play.

Common symptoms include:

  • Excessive play in the handwheels.

  • Irregular slide movement.

  • Difficulty adjusting the tool position.

  • Ineffective locking mechanisms.

  • Worn feed screws or nuts.

  • Damaged handwheels.

A certain amount of backlash can be normal in a feed screw mechanism, but excessive backlash may require adjustment or inspection.

Before replacing a part, check the gib adjustments, slideway condition and movement transmission mechanisms.

Our catalogue also includes certain handwheels designed for Holzmann metal lathes.

These handwheels must not be considered compatible with a Bernardo lathe without checking their exact specifications.

How to Identify the Correct Spare Part for Your Bernardo Metal Lathe

Before ordering a Bernardo metal lathe replacement part, several details should be checked.

1. Identify the exact model

Check the machine identification plate for its model reference, such as Bernardo Profi 400V, Profi 550WQV, Profi 750 or another model.

2. Check the serial number

Certain components may vary depending on the production year or manufacturing version.

3. Consult the exploded parts diagram

The exploded diagram helps identify the position number of the required component.

4. Compare technical specifications

For a belt, check its profile, length, tooth pitch and width.

For motor carbon brushes, check their dimensions and connection arrangement.

For a potentiometer, verify the part reference and electrical specifications.

For a gear, compare the number of teeth, module and dimensions.

5. Contact us if you are unsure

If you cannot find the required part, please provide the machine model, serial number and, if possible, the corresponding item number from the exploded parts diagram.

This information will help us identify the correct component.

Why Is Your Bernardo Metal Lathe Losing Power?

A Bernardo metal lathe that lacks power does not necessarily have a faulty motor.

Several factors can cause reduced performance:

  • A worn or loose drive belt.

  • A slipping belt.

  • An unsuitable spindle speed.

  • Excessive depth of cut.

  • A worn or poorly sharpened cutting tool.

  • Excessive feed rate.

  • Worn motor carbon brushes on applicable models.

  • An electronic speed control problem.

  • Abnormal mechanical resistance.

  • An unsuitable electrical supply.

Before replacing a motor or electronic control board, it is advisable to check the machining conditions and the main transmission components.

Excessive cutting forces can cause the spindle speed to drop even when the motor is functioning correctly.

Why Is Your Bernardo Metal Lathe Noisy or Vibrating?

Metal lathe vibrations can affect machining accuracy and the surface finish of workpieces.

They may be caused by:

  • Incorrect workpiece clamping.

  • Insufficient tool rigidity.

  • A poorly secured tool holder.

  • An unsuitable cutting speed.

  • An incorrectly mounted chuck.

  • A damaged drive belt.

  • A misaligned pulley.

  • Worn or incorrectly adjusted spindle bearings.

  • Excessive play in the slides.

  • Insufficient machine fastening or stability.

It is important to identify the cause before replacing a component.

If excessive vibrations, abnormal noises or significant mechanical play occur, stop the machine and inspect the affected components before using it again.

When Should You Replace a Part on a Bernardo Metal Lathe?

Certain warning signs indicate that a component of your Bernardo metal lathe should be inspected.

Common symptoms include:

  • The drive belt has cracks or damaged teeth.

  • The motor runs, but the spindle is no longer driven correctly.

  • The lathe struggles to start.

  • Abnormal sparking occurs in a commutator-type motor.

  • Spindle speed becomes irregular.

  • A handwheel or feed mechanism no longer works correctly.

  • A gear has broken teeth.

  • A bearing produces unusual noises.

  • The lathe vibrates excessively.

  • An electrical component stops responding.

These symptoms should be investigated before carrying out repairs.

Replacing a component should address the actual cause of the malfunction.

How to Maintain Your Bernardo Metal Lathe

Regular maintenance helps preserve the accuracy, performance and service life of your Bernardo metal lathe.

Recommended maintenance practices include:

  • Regularly remove metal swarf using suitable tools.

  • Clean and lubricate the slideways according to the manufacturer's recommendations.

  • Check the condition of the drive belts.

  • Inspect the pulleys and their alignment.

  • Watch for unusual noises and vibrations.

  • Check the lubrication points and oil levels specified for the machine.

  • Inspect the clamping of tools and workpieces.

  • Check the operation of the feed mechanisms.

  • Clean and protect metal surfaces against corrosion.

  • Regularly inspect safety devices.

  • Use cutting tools suited to the materials being machined.

  • Follow recommended cutting speeds and feed rates.

Before carrying out maintenance or repairs, stop the machine, disconnect it from the electrical supply and wait until the spindle has completely stopped.

Never remove metal swarf with bare hands. Use a suitable brush or tool.

Preventive maintenance helps reduce breakdowns and premature component wear.

Why Buy Bernardo Metal Lathe Spare Parts from Probois Machinoutils?

At Probois Machinoutils, we understand that a breakdown can quickly put an essential metalworking lathe out of service.

That is why we are gradually expanding our selection of Bernardo metal lathe spare parts, making machine maintenance and repairs easier.

By choosing Probois Machinoutils, you benefit from:

  • A dedicated category for Bernardo metal lathe replacement parts.

  • Drive belts for certain Profi 400V, Profi 550 and Profi 750 models.

  • Motor carbon brushes and brush holders for compatible machines.

  • Electrical and transmission components according to the part reference.

  • A growing catalogue designed to meet repair requirements.

  • Assistance with identifying suitable parts for your machine.

  • Experience supplying spare parts for machine tools.

  • An after-sales service able to review specific spare parts requests.

Looking for a spare part that is not yet listed in our catalogue?

Please provide the exact model of your Bernardo metal lathe, its serial number and, if possible, the position number of the required part on the exploded parts diagram.

We can review your request and check possible sourcing options.

Discover our selection of spare parts for Bernardo Profi 400V, Profi 550, Profi 750 and other compatible metal lathe models, and extend the service life of your machine through proper maintenance and the replacement of defective components.
