Trapezoidal belt for table saw Bernardo STS1300ECO and STS1600ECO
V-belt for table saw Bernardo STS1300ECO and STS1600ECO
V-belt for table saw Bernardo STS1300ECO and STS1600ECO
Riving knife for table saw Bernardo STS1300ECO, STS1600ECO, PKS250P
M6x18 blade fixing screw for Bernardo STS1300, STS1600 and PKS250P circular saws. This screw is used to secure and hold the blade clamping assembly on the saw spindle.
Saw blade flange for Bernardo circular table saws, compatible with STS1300, STS1600 and PKS250P models. This replacement part helps secure and correctly position the saw blade on the machine spindle.
The Bernardo STS1300ECO and STS1600ECO table saws are woodworking machines designed to perform accurate cutting operations in the workshop. Equipped with an aluminium sliding table, a cast iron worktable and adjustable saw blade mechanisms, they allow users to carry out a variety of cutting tasks on timber and suitable wood-based panels.
These two models belong to the Bernardo sliding table saw range, intended for demanding DIY enthusiasts, woodworking hobbyists and smaller workshops looking for versatile woodworking equipment.
The main difference between the two versions is the length of the sliding table. The Bernardo STS1300ECO features a 1300 mm sliding table, while the Bernardo STS1600ECO is equipped with a 1600 mm sliding table.
Both machines use a 254 mm diameter saw blade with a 30 mm bore and feature adjustment mechanisms that allow the blade height and tilt to be adapted to the cutting operation.
Like any woodworking machine, a circular table saw contains numerous mechanical and electrical components that may become worn or damaged over time.
At Probois Machinoutils, we offer a selection of spare parts for Bernardo STS1300ECO and STS1600ECO table saws to help users maintain their machines, replace defective components and carry out necessary repairs.
Our catalogue includes a V-belt, a riving knife and an M6 × 18 blade fixing screw.
These components perform essential functions related to power transmission, cutting safety and the secure fastening of the saw blade assembly.
The Bernardo STS1300ECO and STS1600ECO share many technical characteristics, although their designs are not completely identical.
The most noticeable difference concerns their aluminium sliding tables, which vary in length depending on the model.
The STS1300ECO features a sliding table travel of 1300 mm, while the STS1600ECO offers a travel of 1600 mm.
Both machines are designed to accommodate a 254 mm diameter saw blade and provide a maximum cutting depth of 80 mm at 90° and 63 mm at 45°, according to the manufacturer's specifications.
They are also equipped with a rip fence, table extensions and a 100 mm dust extraction connection.
Single-phase 230 V and three-phase 400 V versions may have differences in certain electrical components.
It is therefore essential to check the exact machine reference before ordering a replacement part.
Even when two models use similar components, compatibility should be confirmed using the original part reference or the corresponding exploded parts diagram.
The V-belt for Bernardo STS1300ECO and STS1600ECO circular table saws is a drive component designed to transfer power from the motor to the saw blade drive mechanism.
This part plays an important role in the operation of the machine.
During cutting, the motor drives the transmission system, allowing the saw blade to rotate at the speed specified by the manufacturer.
The belt must be correctly positioned and maintained in good condition to ensure consistent power transmission.
Over time, a drive belt may gradually wear due to mechanical loads, changes in operating conditions and regular use.
A deteriorated belt may cause slipping, unusual noises or reduced transmission efficiency.
In some cases, a cracked, frayed or excessively worn belt may eventually break.
We offer a replacement V-belt for Bernardo STS1300ECO and STS1600ECO table saws.
Before fitting a new belt, we recommend checking the condition and alignment of the pulleys, together with the belt tension requirements specified by the manufacturer.
Belt replacement must always be performed with the machine disconnected from the electrical supply.
Several symptoms may indicate that a Bernardo table saw drive belt requires inspection.
An unusual reduction in blade speed under load may suggest a transmission problem.
Unexpected noises coming from the drive mechanism may also occur when a belt is damaged or incorrectly positioned.
Visible wear, cracks or deformation of the belt profile are additional signs that replacement may be necessary.
However, these symptoms are not always caused by the belt itself.
A blunt saw blade, incorrect belt tension, a damaged pulley or a motor fault can produce similar problems.
It is therefore important to carry out a proper diagnosis before replacing a component.
A drive belt in good condition helps maintain smooth power transmission and reduces unnecessary strain on the other mechanical parts.
The riving knife for Bernardo STS1300ECO and STS1600ECO table saws is an essential safety component.
Positioned behind the saw blade, it helps keep the two sides of the workpiece separated after the blade has passed through the material.
Its main purpose is to reduce the risk of the wood closing around the blade, which can contribute to a sudden and dangerous kickback.
A correctly fitted and adjusted riving knife therefore plays an important role in safe table saw operation.
Our catalogue includes a riving knife compatible with Bernardo STS1300ECO, STS1600ECO and PKS250P table saws, according to the listed machine references.
This component may need replacing when the original riving knife is bent, damaged or no longer suitable for use.
It is essential to select a riving knife with the correct dimensions, thickness and mounting arrangement for the machine and saw blade.
An unsuitable or incorrectly adjusted riving knife may compromise both the operation of the saw and user safety.
It must never be removed for cutting operations that require its presence.
During rip cutting, some pieces of timber contain internal stresses that may cause the cut to close after the blade has passed through.
This can result in the material contacting the rear section of the rotating blade.
The table saw riving knife helps reduce this risk by maintaining separation between the two sides of the workpiece.
To perform its function correctly, it must be positioned according to the manufacturer's instructions.
Its alignment with the saw blade and its suitability for the blade thickness must also be checked.
A bent, loose or incorrectly installed riving knife must not be used.
Before operating the machine, it is recommended to check that all required safety devices are present and in good condition.
The riving knife is one of the components that deserves particular attention during regular table saw maintenance.
The M6 × 18 blade fixing screw for Bernardo STS1300ECO and STS1600ECO table saws is used in the fastening assembly that secures the saw blade to the saw spindle.
This mechanical component contributes to the correct retention of the blade clamping assembly.
Our catalogue includes an M6 × 18 blade fixing screw compatible with Bernardo STS1300, STS1600 and PKS250P table saws, provided that its specifications match the original installation.
The screw features an M6 thread, a stated length of 18 mm and a hexagonal head.
Like any fastening component exposed to mechanical loads and vibration, it must remain in good condition.
A screw with damaged threads, a worn head or visible deformation should be replaced with a suitable reference.
It is particularly important to respect the specifications of the original fixing screw.
A screw with incorrect dimensions or an unsuitable thread may compromise the security of the blade fastening assembly.
Installation must be carried out in accordance with the manufacturer's instructions, particularly regarding the tightening direction and procedure.
Before ordering a Bernardo circular table saw spare part, it is essential to identify the exact machine model.
The STS1300ECO and STS1600ECO share many similarities, but certain components may differ depending on the version.
The machine identification plate is the first place to check.
It generally provides the model designation, electrical specifications and other information needed to identify the equipment.
We also recommend consulting the Bernardo STS1300ECO or STS1600ECO exploded parts diagram.
This document shows the different mechanical assemblies and helps identify components by their position or original part number.
For a drive belt, the belt profile and dimensions should be verified.
For a blade fixing screw, the thread, length and fastening specifications must correspond to the original component.
For a riving knife, the dimensions, mounting system and compatibility with the cutting assembly must be checked.
Following these steps helps reduce ordering mistakes and ensures that the selected component is suitable for the machine.
A Bernardo STS1300ECO or STS1600ECO table saw may develop different symptoms indicating that maintenance or repair is required.
If the saw blade appears to lose speed during cutting, it is important to check the blade condition, cutting conditions and transmission components.
A worn or slipping drive belt may be responsible, although other mechanical or electrical problems can cause similar symptoms.
Unusual vibrations may result from a loose component, a damaged pulley or a problem within the cutting mechanism.
Abnormal noises should also be investigated before continuing to operate the machine.
If the timber closes around the saw cut or the workpiece behaves unexpectedly, the riving knife adjustment and guiding conditions should be checked.
If a component of the blade clamping assembly is damaged, the machine must not be returned to service until the problem has been resolved.
In every case, an accurate diagnosis is preferable to replacing several components without identifying the actual cause of the malfunction.
Regular maintenance helps preserve the reliability and cutting accuracy of Bernardo STS1300ECO and STS1600ECO table saws.
After each use, accumulated sawdust should be removed from the worktable and accessible areas of the machine.
The sliding table should be kept clean to maintain smooth movement.
Fences and adjustment mechanisms should also be inspected and maintained according to the manufacturer's recommendations.
The condition of the drive belt deserves particular attention, especially when the machine is used frequently.
It is also important to check accessible mechanical fasteners without altering the safety settings specified by the manufacturer.
The saw blade must be suitable for the material being cut and kept properly sharpened.
A blunt blade increases cutting resistance and may place additional strain on the motor and transmission.
Using a suitable wood dust and chip extraction system helps reduce the accumulation of sawdust and airborne particles in the workshop.
The STS1300ECO and STS1600ECO are equipped with a 100 mm dust extraction connection, allowing a compatible extraction system to be connected.
Before each use, it is important to inspect the blade guard, riving knife, fences and the correct operation of the machine controls.
Replacing a worn component on a Bernardo table saw is often a cost-effective solution when the machine remains in good overall condition.
A deteriorated drive belt, damaged fixing screw or riving knife requiring replacement does not necessarily justify purchasing an entirely new table saw.
When the correct replacement part is available and the rest of the machine operates properly, a suitable repair can extend its service life.
This approach also helps reduce waste and avoid the premature replacement of woodworking equipment.
However, safety must always remain the priority.
Components associated with blade fastening and protective devices must be replaced and installed correctly.
A machine with a defect that could compromise safe operation must not be used until the problem has been resolved.
At Probois Machinoutils, we offer a selection of spare parts for Bernardo STS1300ECO and STS1600ECO table saws to help you maintain and repair your woodworking machinery.
In this category, you can find:
A replacement V-belt for Bernardo STS1300ECO and STS1600ECO.
A riving knife for Bernardo STS1300ECO, STS1600ECO and PKS250P.
An M6 × 18 blade fixing screw for Bernardo STS1300, STS1600 and PKS250P.
These components allow maintenance and repairs to be carried out on the drive transmission, safety equipment and saw blade fastening system.
Before ordering, we recommend checking the exact model of your saw and confirming the compatibility of the required part.
If the component you need is not listed in our catalogue, our customer service team may be able to help identify it using the machine identification plate or exploded parts diagram, subject to availability from the manufacturer.
Discover spare parts for Bernardo STS1300ECO and STS1600ECO table saws at Probois Machinoutils to maintain your equipment, carry out necessary repairs and extend the service life of your woodworking machine.
