Go from a 20 mm shaft to a 30 mm shaft using this sleeve fitted with spacer rings.
Set of 2 reduction bush with collar to put a tool bore 30 mm on spindle moulder 20 mm
Set of 2 reduction bush with collar to put a tool bore 50 mm on spindle moulder 30 mm
Set of 2 reduction bush with collar to put a tool bore 50 mm on spindle moulder 40 mm
Set of 10 millimeter rings for spindle moulder bore 30 mm
Set of 10 intermediate collars for spindle moulder bore 30 mm
Set of different rings giving a total height of 130 mm for spindle moulder's shaft
Set of 10 millimeter rings for spindle moulder bore 50 mm
Set of 10 intermediate collars for spindle moulder bore 50 mm
Set of different rings giving a total height of 130 mm for spindle moulder's shaft
Spacer and adjustment rings for spindle moulders are used to accurately position cutters on the machine spindle and to fill the available space between the different components of the tooling assembly.
Available in different thicknesses, they are designed to adjust cutter height, provide precise spacing and complete tooling stacks on the spindle.
Spindle spacer rings are fitted directly onto the spindle, above, below or between cutters depending on the tooling arrangement.
They can be used to fill the remaining space on the spindle and correctly position a cutter block, cutter or several tools mounted together.
Different ring thicknesses make it easy to adapt the tooling arrangement to the required height.
Millimetre spacer rings are available in various thicknesses for accurately spacing and positioning cutters on the spindle.
By combining several rings, different overall thicknesses can be obtained, making it possible to precisely adjust the position of the cutter according to the machining operation.
For applications requiring greater precision, fine adjustment rings allow very small corrections to the cutter position.
Rings in different thicknesses, including fractions of a millimetre, make it possible to fine-tune the cutter position without changing the complete tooling arrangement.
They are particularly useful for achieving a precise cutter height adjustment or adjusting the spacing between several cutters mounted on the same spindle.
Spacer rings must always be selected according to the diameter of the spindle.
They are available for 30 mm spindles, commonly used on many spindle moulders and combination woodworking machines, as well as for 50 mm spindles found on certain machines.
Before ordering a spacer or adjustment ring, the main specifications to check are:
Several rings can be combined to obtain the required overall thickness and accurately adjust the position of the cutter.
Our spacer and adjustment rings can be used on various spindle moulders and combination woodworking machines, provided that the bore diameter exactly matches the machine spindle diameter.
They may be suitable for certain machines from Kity, Leman, Holzmann, Bernardo, Holzprofi, Jean l'Ébéniste and many other brands.
