Set of 2 reduction bush with collar to put a tool bore 30 mm on spindle moulder 20 mm
Set of 2 reduction bush with collar to put a tool bore 50 mm on spindle moulder 30 mm
Set of 2 reduction bush with collar to put a tool bore 50 mm on spindle moulder 40 mm
Tightening screw length 55 mm of the router shaft in M16 Holzmann FS160L, Jean l'ébéniste MX5108 and Bernardo T500PF
M16 spindle moulder shaft tightening nut for Holzmann FS160L, Jean l'ébéniste MX5108 and Bernardo T500PF
M14 screw for spindle moulder Bestcombi, Kity 429 and Molda 2.0
T-bushing diameter 70 mm and threaded screw M16 for spindle moulder shaft 50 mm
Screws, nuts and clamping accessories for spindle moulder spindles are used to securely hold cutters, tooling and other components fitted onto the machine spindle. These parts are essential for ensuring a correct assembly suited to the spindle and tooling being used.
Probois Machinoutils offers a range of fastening and clamping components for spindle moulders, including screws and nuts for spindle shafts with different thread sizes such as M14 and M16.
This category includes components for clamping tooling at the end of the spindle as well as various fastening parts used when installing spindle moulder cutters and cutter blocks.
A spindle clamping screw is used to secure the complete assembly consisting of the cutter, spacer rings and other components fitted onto the spindle.
Depending on the machine design, the screw is fitted directly into the threaded hole at the end of the spindle. It must therefore have a compatible thread diameter, thread pitch and length.
M14 and M16 threads are commonly found on various spindle moulders and combination woodworking machines, but the spindle diameter alone is not sufficient to determine which thread is required.
On some spindle moulders, the tooling is secured using a clamping nut fitted onto the threaded end of the spindle.
The nut is used to clamp the cutters, spacer rings and other components installed on the spindle. It must exactly match the diameter and thread pitch of the machine spindle.
An unsuitable nut should never be forced onto the spindle: two threads that appear to have the same diameter may have different pitches and therefore be incompatible.
Some cutter blocks and accessories also require specific fastening screws for installation on the spindle moulder.
We offer various screws for fitting cutter blocks, spindle sleeves and accessories, as well as specific parts suitable for certain older and modern machines.
The correct component should always be selected according to the original assembly specifications: thread diameter, thread pitch, screw length and the design of the screw head or contact surface.
Before ordering a screw or nut for your spindle moulder, it is essential to identify the thread used on the machine accurately.
A 30 mm spindle, for example, may have an M14, M16 or another thread depending on the brand, model and year of manufacture.
You should therefore never select a screw based solely on the spindle diameter. Check:
A damaged spindle clamping screw or nut should be replaced when its condition no longer allows the tooling to be securely mounted.
A damaged thread, badly worn screw head or deformed nut can make installation difficult and may also damage the spindle thread.
When replacing these components, we recommend comparing the new part with the original fastening component and checking all dimensions before installation.
Our screws, nuts and clamping accessories can be suitable for various spindle moulders and combination woodworking machines, provided that the dimensions and thread type are checked beforehand.
These parts may be suitable for machines from Kity, Leman, Holzmann, Bernardo, Holzprofi, Jean l'Ébéniste and many other brands.
