Oil dipstick reference 5906208055 for Scheppach SG2000 generator and Scheppach HP1300 vibrating plate
Ignition coil 168F LZD2012012033 for vibrating plate, generator and scarifier Scheppach and Woodstar
Launcher 3904601195 or 3904601088 for mini dumper, vibrating plate and energy generator Scheppach and Woodster
Pair of carbon brushes, part number 3906203179, for Scheppach and Woodstar generators, according to the following list : LIST OF COMPATIBLE MACHINES
Has your Woodstar generator already helped you out more than once and is now starting to show signs of wear? A recoil starter that sticks, an engine that is difficult to start, an irregular power supply or a faulty component does not necessarily mean that the entire generator needs to be replaced. On this type of equipment, many parts can be replaced individually to restore the machine to good working order and extend its service life.
This category brings together spare parts for Woodstar and Woodster generators for maintenance, troubleshooting and repairs. Depending on the model and version, some parts may also be shared with Scheppach generators. It is therefore essential to check the list of compatible machines shown on each product page before ordering.
A generator is often used when it is genuinely needed: to provide electricity on a job site, in a workshop, in an outbuilding or occasionally when mains power is unavailable. This is precisely why regular maintenance and the replacement of worn parts are important. A machine that may remain unused for several months needs to be able to start properly on the day you need it.
Depending on your machine model, various Woodstar generator spare parts may be required over the years: recoil starter, carburettor, ignition coil, spark plug, fuel filter, fuel tank cap, oil dipstick, oil level sensor, fan, switch, electrical components, mechanical parts and fixings.
Not every fault requires several components to be replaced. The most important thing is to identify the symptom accurately and methodically check the parts that may be responsible. A generator that no longer starts may, for example, have an ignition, fuel supply or starting-system problem, while irregular running may have a different cause.
Replacing only the genuinely faulty part can often bring a generator back into service and allow it to continue working for many more years.
The generator recoil starter is used every time a manually started model is switched on. Over time, the starter rope, recoil spring or internal mechanism can wear. A rope that no longer retracts correctly, a handle that pulls without engaging or a mechanism that no longer turns the engine are all signs that the recoil starter should be inspected.
If the recoil starter offers unusual resistance, it is best not to force it. Excessive force can damage other components and turn what could have been a relatively simple repair into a more complicated one.
Some recoil starters may be fitted to several Scheppach or Woodster machines, including generators and other petrol-powered equipment. However, visual similarity alone is not enough to guarantee compatibility: always check the part reference and the list of compatible models.
After a long period of storage, the fuel system is one of the first areas to check when a Woodstar petrol generator is difficult to start or runs irregularly. Old fuel, deposits or contamination can interfere with the engine's fuel supply.
The carburettor plays an essential role in controlling the air-fuel mixture. If it is dirty or faulty, the engine may be difficult to start, run unevenly or stall. The fuel filter, fuel lines and tank should also be inspected when the fuel supply appears insufficient.
Before replacing the complete carburettor, it is therefore advisable to inspect the entire fuel system. This can avoid replacing a part unnecessarily when the problem is simply caused by a clogged filter, deteriorated fuel or another component in the circuit.
For a petrol engine to start correctly, its ignition system must be in good condition. The spark plug is a relatively simple service part, but its condition can directly affect starting and engine operation.
A dirty or worn spark plug, or one with an incorrect electrode gap, can cause starting difficulties or misfiring. The ignition coil is another component to check when there is no spark or the ignition system appears to be faulty.
However, it is better to proceed step by step rather than immediately replacing the coil. The spark plug, its connection and the various components of the ignition circuit should be checked to identify the true cause of the problem.
The oil level is essential for the correct operation and service life of a petrol engine. Depending on the generator, different components may be involved in checking or monitoring the oil level, including the oil dipstick, oil cap, oil level switch or sensor.
A low oil level should never be ignored. On some engines, a safety system can prevent starting or stop the engine when the oil level is too low. Before investigating a more complex fault, checking the oil level and condition should therefore be one of the basic checks carried out.
Regular engine maintenance in accordance with the recommendations for the relevant model helps reduce wear and maintain reliable starting.
A generator is not necessarily used every day. It may remain stored for several weeks or months before being brought out again for a job, some work around the property or a temporary need for electricity. And it is often at precisely that moment that you discover the recoil starter no longer works properly, the engine refuses to start or a small component has deteriorated over time.
In this situation, it would be a shame to replace the entire machine if a targeted repair is all that is needed. A recoil starter, spark plug, ignition coil, carburettor or another component may be enough to bring back into service a generator you already know and that still meets your needs perfectly well.
Being able to find spare parts for an older Woodstar or Woodster generator therefore helps you keep your equipment for longer, avoid unnecessary replacement and repair a machine that may still provide many years of useful service.
Woodstar and Woodster sold a variety of machines, and some parts may be shared with Scheppach models. However, this does not mean that two components that look alike are automatically interchangeable.
Before ordering, carefully check the exact model of your generator, the part reference, its position number on the exploded diagram when available, and any manufacturing date or serial number information specified on the product page.
This check is particularly important for engine parts, carburettors, recoil starters and electrical components. Differences in mounting points, connections or technical specifications can make a part incompatible even when its external appearance seems identical.
With the correct Woodstar generator spare parts, it is often possible to considerably extend the working life of your machine. Regular maintenance, suitable fuel, oil in good condition and the replacement of genuinely worn components help keep your generator ready to operate whenever you need it.
The aim is to repair logically: identify the symptom, inspect the relevant components and replace only the faulty part. Whether it is a recoil starter, spark plug, ignition coil, carburettor or a component related to the oil or electrical system, the right repair can prevent a perfectly serviceable machine from being discarded.
