The Scheppach MS750-53, MS750-53B and Woodstar TT750-53 / TT750-53B are robust petrol lawn mowers that can still be found working in many gardens today. With their 53 cm cutting width and self-propelled drive system, they were designed to efficiently maintain relatively large lawn areas.

These machines have been widely sold and, several years after purchase, it is perfectly normal to look for spare parts for Scheppach MS750-53 and Woodstar TT750-53 lawn mowers. A blade eventually becomes blunt, a drive belt wears out, a cable may break, and wheels or transmission components can develop play over time.

But if the lawn mower is still in good overall condition, why replace the whole machine because of one worn part? That is exactly the advantage of spare parts: repair what actually needs repairing and allow a reliable machine to keep working for many more seasons.

This category therefore brings together the main replacement parts for Scheppach MS750-53, MS750-53B and Woodstar TT750-53(B) lawn mowers.

Spare parts to maintain your MS750-53 or TT750-53

A petrol lawn mower operates in fairly demanding conditions: engine vibration, dust, moisture, grass clippings, uneven ground and occasionally an unexpected encounter with a stone or tree root!

Over the years, certain components naturally become wear parts.

For these lawn mowers, you may find:

• 530 mm lawn mower blade.

• Blade holder.

• Blade fixing bolt.

• Drive belt.

• Belt guard.

• Transmission gearbox.

• Left and right drive gears.

• Rear axle.

• Front and rear wheels.

• Bowden cables.

• Drive lever.

• Brake lever.

• Springs and tension springs.

• Air filter.

• Mulching kit.

• Side discharge deflector.

• Grass catcher and collection bag.

• Grass catcher support.

• Cleaning connection.

• Pins, washers, nuts and screws.

These parts allow you to carry out both routine maintenance and more extensive repairs to the cutting or drive system.

530 mm blade for Scheppach MS750-53

With their 53 cm cutting width, these lawn mowers use a 530 mm blade designed for their mower deck.

For compatible versions, you can find the 530 mm blade, part number 7911200605.

The blade is naturally one of the hardest-working components of a lawn mower. It rotates at high speed and can encounter stones, small branches, roots and other objects hidden in the grass.

Over time, it can:

• Lose its cutting edge.

• Develop impact damage.

• Wear unevenly.

• Become bent after a significant impact.

• Cause vibration when damaged.

A blade in good condition provides a cleaner and more even cut.

If the blade has suffered a significant impact, remember to inspect the blade holder and blade fixing bolt as well.

Blade holder for Scheppach and Woodstar 530 mm lawn mowers

The blade holder is an essential component of the cutting system, providing the connection between the engine and the lawn mower blade.

For certain versions of these lawn mowers, the blade holder, part number 3911205013, is available for compatible 530 mm cutting-width models.

The blade fixing bolt, part number 5911203019, is also among the available spare parts.

After a significant impact with a stone or tree stump, replacing only the blade may not always be enough. A damaged or bent blade holder should also be inspected.

It only takes a few extra minutes and can prevent a new blade from being fitted onto an already damaged component.

750Li drive belt for Scheppach MS750-53 and Woodstar TT750-53

On a self-propelled lawn mower, the drive belt works practically every time the machine is used.

For certain machines, particularly series no. 0177, the 750Li drive belt, part number 3911205011, is available.

Over time, a belt can stretch, crack, slip or eventually break.

The symptoms are generally quite easy to recognise:

• The lawn mower no longer moves forward as effectively.

• The self-propelled drive operates intermittently.

• More effort is required to push the machine.

• The transmission appears to slip.

• The mower no longer moves forward even though the engine is running normally.

However, a self-propelled drive problem is not necessarily caused by the belt. Drive gears, springs, wheels and the transmission gearbox may also be involved.

Drive belt guard

The drive belt guard helps prevent grass and debris underneath the mower deck from directly reaching the transmission mechanism.

Depending on the version of your lawn mower, different part numbers may be used, including belt guard 5911216001 or 3911205014 on certain configurations.

This component may seem relatively unimportant, but it helps protect a much more expensive mechanism.

It is often the kind of small part you never really think about... until it breaks or goes missing!

Transmission gearbox for MS750-53 and TT750-53

The transmission gearbox is at the heart of the lawn mower's self-propelled system.

For certain compatible versions, the transmission gearbox, part number 5911216014, is available as a replacement part.

If the mower is no longer driving correctly, however, it is advisable to inspect the complete system before assuming that the gearbox needs replacing.

The problem may also come from:

• The drive belt.

• A spring.

• A cable.

• A drive gear.

• A wheel component.

• A pin or fixing component.

A proper diagnosis can sometimes avoid replacing an important and more expensive component when a much simpler part is actually causing the problem.

Left and right drive gears

The drive wheels use various mechanical components to transmit movement.

For certain versions of these Scheppach and Woodstar lawn mowers, you can find:

• Left drive gear, part number 5911204024.

• Right drive gear, part number 5911204025.

These components can wear after several years of use and cause reduced or irregular self-propelled performance.

If one wheel appears to be driven less effectively than the other, or if the transmission produces unusual noises, the drive gears are among the components worth inspecting.

Rear axle and drive wheels

The rear axle is also part of the lawn mower's drive system.

A rear axle for the drive wheels is available for certain versions of these lawn mowers, together with various associated components.

The wheels themselves may also need replacing after several years.

Depending on the machine version, you may find:

• Front wheel, part number 5911216009, for certain series no. 0177 machines.

• Rear wheel, part number 5911216019, for various compatible models.

A worn wheel may develop excessive play, become difficult to rotate or affect the correct operation of the self-propelled system.

Bowden cables and controls

Bowden cables are among those components that work hard without us really thinking about them.

Every time a control is operated, the corresponding cable is put under tension.

Over the years, a cable can:

• Fray.

• Stretch.

• Become difficult to operate.

• Seize inside its outer casing.

• Break.

For certain versions, you can find the 1330 mm throttle Bowden cable, part number 5911201001, particularly for some series no. 0177 machines.

A 1540 mm cable, part number 5911204019, is also used on various compatible models.

Before ordering, always check the length, end fittings and, most importantly, the part number of your original cable.

Drive lever and brake lever

The levers on the handlebar are constantly operated during mowing.

The drive lever engages the self-propelled system, while the brake lever plays an important role in the operation and safety of the machine.

The brake lever, part number 3911201002, is among the spare parts available for various compatible Scheppach and Woodstar lawn mowers.

A broken lever may seem like a minor fault, but sometimes such a small component is enough to make the entire lawn mower unusable. Being able to replace only the damaged part therefore makes perfect sense.

Air filter for Scheppach MS750-53

A lawn mower engine constantly operates in an environment filled with dust and fine particles.

The air filter is therefore essential for helping protect the engine.

The air filter, part number 7850000045, is available for certain versions of the Scheppach MS750-53.

A heavily clogged filter can restrict the engine's air supply. It should therefore be checked regularly and replaced when it becomes excessively dirty or damaged.

It is a simple maintenance operation, but one of those good habits that can help keep your lawn mower working properly for longer.

Mulching kit for MS750-53

Certain versions can be fitted with a mulching kit.

Mulching finely chops the grass clippings before returning them to the lawn instead of collecting them in the grass catcher.

A mulching kit is available for various compatible lawn mowers, including certain versions of the Scheppach MS750-53.

However, pay attention to production dates: some of these parts are only intended for machines manufactured before a specific date. Checking the exact part number therefore remains essential.

Side discharge deflector for Scheppach and Woodstar lawn mowers

For configurations with side discharge, the side deflector directs the cut grass away from the side of the mower.

Depending on the version, you may find part numbers 5911216006 or 5911204049.

A damaged, broken or missing deflector can therefore be replaced separately without having to replace the complete mower deck.

Grass catcher and grass bag support

The grass catcher is probably one of the most frequently handled parts of a lawn mower.

It is removed, emptied and refitted, sometimes dozens of times during a single mowing session.

It is therefore hardly surprising that certain components eventually wear out.

For these lawn mowers, various grass collection parts may be available separately:

• Upper grass catcher section.

• Grass bag or lower section.

• Grass catcher support.

• Fixing components.

Being able to replace only the damaged section is particularly useful when the rest of the grass catcher is still perfectly serviceable.

Mower deck cleaning connection

Certain versions also feature a garden hose connection on the mower deck.

It makes cleaning underneath the lawn mower easier after use.

It is a very small component, but it can be particularly convenient when damp grass has accumulated underneath the deck.

Regular cleaning helps reduce the build-up of grass residue and makes general mower maintenance easier.

Springs, pins, washers and small mechanical parts

A lawn mower also contains many small components that may only cost a few pounds or euros but can prevent a complete mechanism from working when they are missing or broken.

For certain versions, these include:

• Spring, part number 5911216013.

• Tension spring.

• Mulching cover spring.

• Ø 5 x 21.6 mm pin, part number 5911216015.

• Washers.

• M8 nuts.

• Screws and fixings.

• Handlebar knobs and locking handles.

Being able to obtain these small components separately can avoid unnecessarily replacing an entire assembly.

Scheppach MS750-53 and Woodstar TT750-53: check the exact version

This is the most important point to consider before ordering a spare part.

Depending on the production year and series, several versions of the Scheppach MS750-53, MS750-53B and Woodstar TT750-53(B) may exist.

Certain parts are specifically intended for series no. 0177 machines, while others may differ according to the production date.

Some components may also vary depending on whether the machine was manufactured before or after July 2021, while several parts are specified for machines manufactured before August 2022.

Before ordering, take a moment to check:

• The exact lawn mower model.

• Scheppach MS750-53 or MS750-53B.

• Woodstar TT750-53 or TT750-53B.

• Serial number.

• Production date.

• Original part number.

• Position and part number shown on the exploded diagram for your machine.

Do not rely only on the photograph of the part

This is a very easy mistake to make when searching for spare parts.

You remove the old component, find a photograph that looks exactly the same and naturally assume that you have found the correct replacement.

Unfortunately, two almost identical parts can have slightly different dimensions, mounting points or specifications.

This is particularly true for drive belts, Bowden cables, wheels, drive gears, blade holders and transmission components.

The part number shown on the correct exploded diagram remains the best way to identify the right component.

It may take a few extra minutes before ordering, but that is still much quicker than dismantling the mower only to discover that the new part does not fit!

Scheppach and Woodstar: closely related machines

Scheppach and Woodstar have marketed machines that share many components.

This is why certain spare parts may be common to a Scheppach MS750-53 and a Woodstar TT750-53, as well as other lawn mower models from the same group.

However, this does not mean that every component is automatically interchangeable.

Once again, checking the manufacturer's part number and the exploded diagram is the best way to confirm compatibility.

Repair your lawn mower rather than replace it

After several years, it can be tempting to think that a lawn mower showing a few problems has simply become too old.

Yet poor self-propelled performance may only be caused by a drive gear or belt, vibration may come from a damaged blade, and a control that no longer works may simply be due to a broken Bowden cable.

If the engine, mower deck and general structure of the machine are still in good condition, it would be a shame to replace the entire lawn mower because of one component.

And there is something satisfying about keeping a mower you have used for years running. You know how it starts, how it behaves and even the little noises it normally makes. Seeing it return to work after simply replacing the right part always brings a little satisfaction!

Find the right part for your Scheppach MS750-53 or Woodstar TT750-53

This category brings together the main spare parts for Scheppach MS750-53, MS750-53B and Woodstar TT750-53(B) lawn mowers, making maintenance and repairs easier.

Depending on your exact version, you may find:

• 530 mm lawn mower blade.

• Blade holder.

• Blade fixing bolt.

• 750Li drive belt.

• Belt guard.

• Transmission gearbox.

• Left and right drive gears.

• Rear axle.

• Front and rear wheels.

• Bowden cables.

• Control levers.

• Air filter.

• Springs.

• Mulching kit.

• Side discharge deflector.

• Grass catcher components.

• Pins, washers, nuts and screws.

Before ordering, always check the spare part number, serial number and production date of your lawn mower whenever this information determines compatibility.

The goal is simple: find the right part first time, repair only what actually needs repairing and keep your Scheppach MS750-53 or Woodstar TT750-53 maintaining your garden for many more seasons.
