Main function

The carbon brushes for various Kity, Scheppach, Holzmann and Parkside machines – Ref. 3902202119 are designed to transmit electrical current to the rotating part of the motor.

Also known as motor brushes, they remain in contact with the commutator while the motor rotates, allowing the motor to receive electrical power and operate correctly.

Carbon brushes are wear parts: their length gradually decreases due to friction against the commutator. Carbon brushes in good condition help ensure smooth motor operation, efficient current transmission and consistent machine performance.

When should the carbon brushes be replaced?

The carbon brushes for various Kity, Scheppach, Holzmann and Parkside machines – Ref. 3902202119 should be replaced in the following cases:

• Carbon brushes are severely worn or have become too short
• Motor is difficult to start or no longer starts
• Machine operates intermittently
• Loss of power during use
• Motor stops unexpectedly
• Abnormally heavy sparking at the commutator
• Unusual noise or irregular motor operation
• Carbon brushes are broken, cracked or damaged

It is recommended to replace both carbon brushes at the same time, even if one appears less worn than the other.

When replacing them, also remember to check the condition of the motor commutator. A heavily scored, burnt or damaged commutator may cause premature wear of the new carbon brushes.

Carbon brush dimensions:

• Width: 14 mm
• Thickness: 6 mm
• Length: 17 mm

This pair of carbon brushes is suitable for the following models:

• Scheppach TS251 — up to 8/2014
• Scheppach TS251 — from 9/2014
• Scheppach HM100L
• Scheppach KG251
• Scheppach HM100Z
• Scheppach HM100ZL
• Scheppach KGZ251
• Scheppach HM100LXU — up to 4/2020
• Scheppach HM100LXU — from 5/2020
• Scheppach MSS10 — up to 4/2020
• Scheppach MSS10 — from 5/2020
• Scheppach HM120L — up to 9/2020
• Scheppach HM120L — from 9/2020
• Scheppach HT850
• Scheppach HMS850 — up to 11/2020
• Scheppach HMS850 — from 11/2020
• Scheppach HMS850 SE
• Scheppach HMS2000
• Scheppach PT900S
• Scheppach THM850
• Scheppach RD204ATG
• Scheppach HT650
• Scheppach HMS1070
• Scheppach ABHD800-BE — from 11/2020
• Parkside PTK 2000 A1
• Parkside PTK2000A1
• Parkside PKZS2000A1 — up to 4/2020
• Parkside PKZS 2000 A1 — up to 4/2020
• Woodster SX 10 L²
• Woodster SL 10 LU
• Woodster SL 10 LXU — up to 4/2020
• Woodster SL 10 LXU — from 5/2020
• Woodster SL 10U
• Woodster SL 10D
• Woodster PT85
• Woodster PT65
• Kity MS254
• Kity PT8500
• Dexter MS SL 10 — up to 4/2020
• Leman Lodra260
• Holzmann KAP255XJL
• Holzmann KAP305J
• Titan TTB342BTE (serial number listed between 00001 and 59999)
• Zipper ZI-HB254
• Zipper ZI-HB204
