Advantages of the JET JPT-410 planer jointer:

• Ultra-fast change from jointer to planer by simultaneously tilting the 2 flaps of the table
• Machined jointer table, in gray cast iron guaranteeing optimal sliding of the workpieces
• Disengageable wood feed in jointer position
• Safety on the protection of the shaft in the planer position
• Resharpenable irons

The JET JPT-410 planer jointer comes with:

• Set of 3 mounted blades
• 100mm suction nozzle
• Jointer Table Precision Guide
• Tiltable shaft protection e
• push button

Technical characteristics of the JET JPT-410 planer jointer:

• Supply voltage: 400V
• Motor power P1-T: 4450W / S6 40%
• Motor power P2-T: 2950W / S1 100%
• Max planing width : 407mm
• Maximum planing height: 3 - 225 mm
• Max. pass thickness (Planing): 4.5 mm
• Max thickness of pass (Thicknesser): 3 mm
• Feed speed: 7 m/min
• Rubber output roller diameter: 32 mm
• Length of the jointer table: 1660 x 410 mm
• Minimum work piece length: 150 mm
• Rotation speed - Planer: 5500 rpm.
• Shaft diameter: 70mm
• Number of irons: 3
• Planing guide (H x W): 150 x 1100 mm
• Guide tilt: +45° / 90°
• Suction connection diameter: 100 mm
• Dimensions: 1600 x 870 x 1000mm
• Net weight (kg): 370 kg
