Advantages of the Bernardo Hobby 910 G metal lathe :

• Control gear allows easy and quick speed change
• High-quality tapered rollerbearings ensure high concentricity of spindle nose (≤ 0,015 mm)
• Powerful motor for high torque, speed range 65 – 1650 rpm
• Wide range of applications: precision mechanics, training and education, etc.
• Logically arranged feed setting allows easy, smooth adjustment
• Solid machine bed with inductive hardened and polished guideways
• Ideal for processing steel, non-ferrous metals and plastics
• Comes complete with leadscrew for thread cutting and automatic longitudinal and cross feed
• Apron features handwheels with fine scale

The Bernardo Hobby 910 G metal lathe comes with :

• 3-jaw chuck 160 mm
• Cross slide with top support
• Dead center
• Change gears
• 4-way tool post holder
• LED machine light
• Chuck guard
• Splash  guard
• Leadscrew cover
• Chip tray
• Stand
• Tools

Technical specifications of the Bernardo Hobby 910 G metal lathe :

• Distance between centers : 910 mm
• Center height : 160 mm
• Swing over bed : 320 mm
• Bed width : 160 mm
• Spindle bore : 38 mm
• Taper at spindle bore : MT 5
• Speed range : (12) 65 - 1650 rpm
• Longitudinal feed : (16) 0,087 - 2,049 mm/rev.
• Cross feed : (16) 0,019 - 0,444 mm/rev.
• Metric thread : (23) 0,25 - 6 mm
• Inch thread : (28) 4 - 120 threads/1“
• Travel of tailstock sleeve : 75 mm
• Taper of tailstock sleeve : MT 3
• Motor power output S1 100% : 1,1 kW / 230 V or 400 V
• Motor power input S6 40% : 1,5 kW / 230 V or 400 V
• Machine dimension (W x D x H)* : 1610 x 700 x 1350 mm
• Weight approx. : 272 kg
