Bernardo DG13MD twist drill bit grinder with dual function (2 to 13 mm Drill Bits)

449.00 € Tax included

Including €0.82 for ecotax

Reference: BDG13MD

The Bernardo DG 13 MD drill sharpener is ideal for grinding HSS, carbide, cobalt etc. spiral drills. The advantage of this model compared to the DG13M or BSG13PRO is the possibility of rear sharpening of the cutting surfaces, which guarantees a perfect drilling result.

Quantity
Factory Shipping, delivery time 5-8 working days

The Bernardo DG13MD sharpener guarantees efficient sharpening of helical drills!

  • Sharpening device for better centering of the drill tip on the workpiece and a reduction in the required feed force
  • Additional station for rear sharpening of cutter edges (free angle) = Double function: quick sharpening of chamfer angle and crown angle
  • Tip angle adjustable from 90° to 135°
  • For sharpening HSS or carbide drills from 2 to 13 mm
  • Precision ball bearing rotor for very quiet operation
  • Precise and fast work results with one simple control

Technical characteristics of the DG13MD metal tool sharpener :

  • Drill diameter: 2 - 13 mm
  • Stitch angle: 90° - 135°
  • Speed: 4800 rpm
  • Motor power: 0.12 kW
  • Voltage: 230 V
  • Length: 280mm
  • Width: 135mm
  • size: 165mm
  • Weight: 8.1 kg

The Bernardo DG13MD sharpener comes with :

  • CBN grinding wheel for HSS drills
  • Collet set ER 20, 3 – 13 mm, 11 pieces
  • (3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 / 11 / 12 / 13 mm)
  • ER 20 collet holder
BDG13MD
