Properties

• Hardened spindle, standard 26 mm bore
• Electronic, stepless speed setting allows ideal adjustment to workpiece
• Serially equipped with longitudinal and cross feed
• Inductively hardened and polished machine bed provides large face
• Constructed according to Bernardo-Standards
• Precise spindle bedding with 2 adjustable precision taper roller bearings
• User-friendly arrangement of control elements on gear head
• Protective switch according to IP54 standards with undervoltage release
• Swivelling mill head extends application area (90° to +90°)
• Mill head with digital display for spindle stroke and speed

Technical specifications

• Turning lathe :
• Distance between centers : 550 mm
• Center height : 125 mm
• Swing over bed : 250 mm
• Spindle bore : 26 mm
• Taper at spindle bore : MK 4
• Speed range, stepless : 50 - 1000 / 100 - 2000 rpm
• Longitudinal feed : (6) 0,07 - 0,40 mm/rev
• Cross feed : (4) 0,03 - 0,075 mm/rev
• Metric thread : (18) 0,2 - 3,5 mm
• Inch thread : (21) 8 - 56 threads/1"
• Travel of tailstock sleeve : 70 mm
• Taper of tailstock sleeve : MT 2
• T-slot size for cross slide : 10 mm
• Motor power output S1 100% : 0,75 kW / 230 V
• Motor power input S6 40% : 1,0 kW / 230 V
• Milling attachment :
• Drilling capacity in steel : 16 mm
• Face mill capacity max. : 50 mm
• End mill capacity max. : 16 mm
• Throat : 150 mm
• Spindle speed, stepless : 50 - 2250 rpm
• Spindle taper : MT 2
• Mill head tiltable : -90° to +90°
• Height adjustment of mill head : 195 mm
• Motor power output S1 100% : 0,50 kW / 230 V
• Motor power input S6 40% : 0,75 kW / 230 V
• Machine dimensions (W x D x H)* : 1210 x 610 x 860 mm
• Weight approx. : 165 kg
• * without stand

Standard accessories

• 3-jaw chuck DK11-125 mm
• Flange 125 mm
• Drill chuck 1 - 13 mm / B 16
• Drill chuck arbor MT 2 / B 16
• Thread dial
• Dead centers
• Change gears
• 4-way tool post holder
• Cross slide with top support
• Digital spindle stroke display
• Digital speed display
• Drawbar M 10
• Chuck guard
• Leadscrew cover
• Tools
