The Bernardo KDH1100 wood lathe is equipped with a mechanical speed variator!

It allows you to vary the speed continuously from 500 to 2000 rpm. A copier comes with.

Advantages of the Bernardo KDH1100 wood lathe:

• Its very rigid traditional cast iron frame gives it a very high stability and a very comfortable working. The cast iron absorbs perfectly all the vibrations.
• Variable speed from 500 to 2000 rpm.
• Its large capacities make it possible to work pieces up to 1100 mm long and 355 mm in diameter.
• Its powerful 1100 W motor, equipped with 10 speeds of 500 to 2000 rpm, is perfectly suited to all jobs.
• The rotating and sliding head allows working large pieces such as trays, plates, containers.
• The wide tool holder is perfectly designed to support the tools and is easy to handle.
• The cast iron base makes it possible to work at the right height without vibration.

The wood lathe comes with: 1 cast iron base, 1 screw plate (Ø 150), 1 feed dog, 1 tool holder, 1 tailstock, 1 copier

Bernardo KDH1100 Wood Lathe Specifications:

• Engine 230V : 750 W
• Absorbed power: 1.5 hp
• 10 speeds of 500 to 2000 rpm: speeds 500, 620, 760, 900, 1050, 1210, 1400, 1590, 1790, 2000 rpm.
• Capacities Between-points: 1100 mm
• Diameter above the bench: 355 mm
• Pin hole: 9.5 mm
• Race of the mobile doll: 57 mm
• Inner cone of fixed and mobile doll: Walrus No. 2
• Weight: 130 kg without the copier

In case of breakage or for the same machine in single phase, see the identical model by clicking here!
