Properties

• Both planing tables feature fine adjustment and are designed with slots to keep noise levels down
• Thicknessing table is guided on four threads to ensure accurate planing of boards, planks, etc.
• Integrated dust extractor guarantees optimal price-performance ratio
• Quick and easy adjustment of chip removal
• Precise planing tables made of aluminium for best results
• Dust hood (Ø 100 mm) can be used for both planing and thicknessing
• Cutterblock comes with HSS-knives
• Corrugated infeed roller ensures safe and consistent workpiece infeed
• Solid planer fence with prism guide can be tilted from 90° to 45°
• Serially equipped with knife gauge to allow accurate adjustment of knives
• Infeed can be switched off when planing

Technical specifications

• Planer
• Planing width : 305 mm
• Table length : 1080 mm
• Table height : 920 mm
• Shaft rotation speed : 6700 rpm
• Cutter knives : 2 pcs.
• Planer shaft diameter : 62 mm
• Planer fence : 640 x 125 mm
• Fence tiltable : 90° to 45°
• Max. cutting depth : 3 mm
• Thicknesser
• Table length : 500 mm
• Working width : 300 mm
• Working thickness, min./max. : 6 - 160 mm
• Max. cutting depth : 2 mm
• Feed speed : 8,5 mm
• Dust extraction outlet : 100 mm / 75 mm
• Motor power output S1 100% : 1,8 KW (2,4 HP)
• Motor power input S6 40% : 2,5 KW (3,4 HP)
• Voltage : 230 V
• Machine dimension (L x W x H) : 1140 x 820 x 1100 mm
• Weight approx. : 94 kg

Standard accessories

• Cutter knives in HSS-quality
• Knife gauge
• Integrated dust extractor
• Waste bag
• 2x Push handle
• Carriage
