General description of the Bernardo HBS450 - 400V band saw :

• Large table with ground surface and T-slot
• Solid gray cast iron handwheels for quiet operation
• Easy-to-adjust aluminum longitudinal guide with quick release system and integrated magnifying glass
• Tilting table from 0° to 45° for angled cuts
• Upper and lower blade guide for precise cuts
• Quality V-belt for optimal torque transmission
• With limit switch for automatic stopping of the machine when opening the upper casing

The Bernardo HBS450 - 400V band saw comes with :

• Blade
• Longitudinal guide with magnifying glass
• Miter guide
• Gray cast iron drive wheels
• 3-bearing blade guide
• Pusher
• Service tools

Technical characteristics of the Bernardo HBS450 - 400V band saw :

• Cutting width: 440 mm
• Cutting height: 345 mm
• Dimensions of the band saw: 3430 x 20 x 0.6 - 4 ZpZ
• Band saw widths: 10 - 32 mm
• Cutting speed: 600 m/min
• Table dimensions: 490 x 590 mm
• Table height: 940 mm
• Table tilt: 0° to 45°
• Ø suction nozzle: 100 mm
• S1 100% continuous power: 2.2 kW (3.0 hp)
• S6 40% power: 3.0 kW (4.0 hp)
• Voltage: 400V
• Machine dimensions (L x D x H): 930 x 880 x 1865 mm
• Weight (approx.): 170 kg
